Маркировка креплений амортизаторов FOX

Поделиться:
Маркировка креплений амортизаторов FOX
Варианты креплений амортизаторов FOX.
Stem Bushing Mount
Stem Mount w/ No Bushing
Eyelet Bushing Mount
Eyelet Sleeve Mount
Bar Pin Moun
Clevis Mount
Eyelet Heim
Taper Pin Mount
OEM
Stem Bushing Mount
     SM1 .500 Stem Mount Kit, Tall Bushing, Long Stem (2.0 Factory Series)
SM2 .500 Stem Mount Kit, Short Buhsing, Long Stem w/ Spacer
SM3 .500 Stem Mount Kit, Short Bushing, Short Stem (2.0 Performance Series)
Stem Mount w/ No Bushing
S1 Short Stem: [1/2-20 Thread, 3.050 TLG]
S2 Long Stem: [1/2-20 Thread, 3.350 TLG]
Eyelet Bushing Mount
EB1 Hourglass Bushing: 0.750 Inner Diameter x 1.300 TLG
EB2 Hourglass Bushing: 0.625 Inner Diameter x 1.300 TLG
EB3 Hourglass Bushing: 0.625 Inner Diameter x 1.460 TLG
EB4 Hourglass Bushing: 0.750 Inner Diameter x 1.460 TLG
Eyelet Sleeve Mount
ES1 Sleeve: 0.478 Inner Diameter X 0.625 Outer Diameter X 1.500 TLG
ES2 Sleeve: 0.506 Inner Diameter X 0.625 Outer Diameter X 1.375 TLG
ES3 Sleeve: 0.506 Inner Diameter X 0.625 Outer Diameter X 1.480 TLG
ES4 Sleeve: 0.482 Inner Diameter X 0.625 Outer Diameter X 1.545 TLG
ES5 Sleeve: 0.478 Inner Diameter X 0.625 Outer Diameter X 1.250 TLG
ES6 Sleeve: 0.478 Inner Diameter X 0.625 Outer Diameter X 1.750 TLG
ES7 Sleeve: 0.478 Inner Diameter X 0.625 Outer Diameter X 1.438 TLG
ES8 Sleeve: 0.478 Inner Diameter X 0.625 Outer Diameter X 2.045 TLG
ES6 Sleeve: 0.560 Inner Diameter X 0.750 Outer Diameter X 1.625 TLG
ES7 Sleeve: 0.560 Inner Diameter X 0.750 Outer Diameter X 1.675 TLG
ES8 Sleeve: 0.560 Inner Diameter X 0.750 Outer Diameter X 1.313 TLG
ES9 Sleeve: 0.560 Inner Diameter X 0.750 Outer Diameter X 1.880 TLG
ES10 Sleeve: 0.630 Inner Diameter X 0.750 Outer Diameter X 2.280 TLG
ES11 Sleeve: 0.630 Inner Diameter X 0.750 Outer Diameter X 1.375 TLG
ES12 Sleeve: 0.510 Inner Diameter X 0.750 Outer Diameter X 1.490 TLG
ES13 Sleeve: 0.560 Inner Diameter X 0.750 Outer Diameter X 1.550 TLG
ES14 Sleeve: 0.560 Inner Diameter X 0.750 Outer Diameter X 2.045 TLG
Bar Pin Mount
BP1 Bar Pin: 3.100 TLG X 0.635 Outer Diameter X 2.818 Bolt Hole Span
BP2 Bar Pin: 3.750 TLG X 0.635 Outer Diameter X 3.515 Bolt Hole Span
BP3 Bar Pin: 3.250 TLG X 0.635 Outer Diameter X 3.060 Bolt Hole Span
BP4 Bar Pin: 3.875 TLG X 0.635 Outer Diameter X 3.736 Bolt Hole Span
BP5 Bar Pin: 3.875 TLG X 0.635 Outer Diameter X 3.736 Bolt Hole Span
BP5 Bar Pin: 4.750 TLG X 0.760 Outer Diameter X 3.780 Bolt Hole Span
BP6 Bar Pin: 4.750 TLG X 0.625 Outer Diameter X 3.938 Bolt Hole Span (-10 Heim)
BP7 Bar Pin: 4.750 TLG X 0.750 Outer Diameter X 3.938 Bolt Hole Span (-12 Heim)
BP8 Bar Pin: 3.875 TLG X 0.625 Outer Diameter X 3.341 Bolt Hole Span (-10 Heim)
Clevis Mount
C1 Clevis: 1.750 W X 2.130 L x 0.575 Thru Bolt Hole (Performance Series)
C2 Clevis: 1.390 W X 2.270 L x 0.590 Thru Bolt Hole (Factory Series)
C3 Clevis: 1.390 W X 2.400 L x 0.580 Thru Bolt Hole (Performance Series)
C4 Clevis: 2770 W X 2.050 L x 0.635 Thru Bolt Hole (Performance Series)
Eyelet Heim
SB1 Spherical Bearing: -8, 0.500 Inner Diameter
SB2 Spherical Bearing: -10, 0.625 Inner Diameter
SB3 Spherical Bearing: -12, 0.750 Inner Diameter
SB4 Spherical Bearing: -14, 0.875 Inner Diameter
SB5 Spherical Bearing: -12, 0.750 Inner Diameter (2.0 Perfromance Series)
Taper Pin Mount
TP1 Taper Pin: 4.845 TLG X 0.712 Outer Diameter
TP2 Taper Pin: 4.050TLG X 0.625 Outer Diameter
OEM
TM OEM Truck Top Mount
